Bubble Infant CPAP II Nasal 02 Oxygen Air Blender Humidifier ODM

Medical equipment, infant Bubble CPAP, nasal CPAP
BUBBLE CPAP

1) AD-II Infant CPAP is a sort of special medial equipment for support of babies breath which devised and manufactured based on the wide application of closed continuous NCPAP in department of pediatrics, use it on the course of ventilation treatment of CPAPNasal-CPAP) for premature infant, neonate, infant to children over 14 years old.
2) Characteristics of Performance:
Compact system structure, all main machine, humidifying machine, air compressor(matching) are all-in-one, which can effectively save space;
Built-in type air and oxygen mixture, combining with real time monitoring of oxygen concentration(guarantee to use over two year s of system oxygen battery), carrying out dual-guarantee on use safety of oxygen, especially for avoiding to the caused complication for wrong use method of oxygen as to premature infant, neonate.
With highly exquisite adjustment of CPAP, It fully guarantees safety of patients that combined system pressure monitoring with safe valve;
It can also expand various of types to sue of infant NCPAP;
It is allowed to choose electronic control high-temperature or automatic control humidifying machines, for making sure that the system keeps on the best humidifying state;
Light pipeline and snuffle, which can reduce resistance of breath pipelines, decrease work of breathing of patients, matching systems fixed equipment, then it can decrease oppression of patients head and face and damage of nasal septum;
Fit for PIICUNICUPICU of department of pediatrics, wards and so on.
3) Technology Parameter
Oxygen percent control (air mixer): 21%-100%
Flow control: 0-18LPM
Continuous CPAP control: 0.1KPa-1.0KPa(1CMH2O-10CMH2O);
Monitoring
Pressure monitoring: 0-3KPa(0-30CMH2O)
Oxygen concentration monitoring: 21%-100%
Pressure safe valve: Pressure is more than 1.5 of control parameter in pipeline of equipment, safe valve will start automatically.
Alarm
Pressure difference alarm: Pressure difference of oxygen supply is between 0.05MPa and 0.12MPa, alarm by sound;
Battery low-voltage alarm: LCD shows LOW BATTERY when voltage reduces to 6.8V0.5V, then alarming(alarm by sound).
General Parameter
Dimension of main machine: WxHxD 24.7cm* 17.5cm*21cm
Weight of main machine: About 6kg
Air source supply: 0.3MPa-0.4MPa
flow control 0-18LPM
oxygen concentration monitoring 21%-100%
pressure monitoring 0-3Kpa (0-30CMH20)
continuous CPAP control 0.1Kpa-1.0Kpa (1CMH2O-10CMH2O)

Oxygen Air Blender Humidifier

ODM Oxygen Air Blender

CPAP II 02 blender

Bubble Infant CPAP II Nasal 02 Oxygen Air Blender Humidifier ODM Images
